MODEL

SP-525M / SP-525MS

SP-525T/SP-525TS

SPINDLE DIA.

3/4",1",1-1/4"(19mm,25.4mm,30mm)

3/4",1",1-1/4"(19mm,25.4mm,30mm)

SPINDLE SPEED

3000/4500/7500/10000 R.P.M

3000/4500/7500/10000 R.P.M

TAPER OF SPINDLE

MK5

MK5

SPINDLE MOTOR

5HP 3Ø OR 7.5HP 3Ø

5HP 3Ø OR 7.5HP 3Ø

SPINDLE TRAVEL

130mm (5")

130mm (5")

SPINDLE CAPACITY UNDER NUT

3-1/4",3-3/4",4-1/2" (3/4",1",1-1/4" SPINDLE)

3-1/4",3-3/4",4-1/2" (3/4",1",1-1/4" SPINDLE)

TILTING ANGLE

_

_5°~90°~ +45°

MAX. TABLE INSERT DIAMETER

220mm (8-5/8")

220mm (8-5/8")

TABLE SIZE

700mm×900mm(27-1/2"×35-1/2")

700mm×900mm(27-1/2"×35-1/2")

TABLE HEIGHT

900mm (35-1/2")

900mm (35-1/2")

SLIDING TABLE SIZE

900×2300mm (35-1/2"×9")

900×2300mm (35-1/2"×9")

SLIDING TABLE TRAVEL

800mm (32-1/2")

800mm (32-1/2")

FENCE SIZE

125×900mm(4-15/16"×35-1/2")

125×900mm(4-15/16" × 35-1/2")

N.W

695 IBS(316 kgs)/744 IBS (338 kgs)

695 IBS(316 kgs)/744 IBS (338 kgs)

G.W

854 IBS (388 kgs)/ 915 IBS (416 kgs)

854 IBS (388 kgs)/ 915 IBS (416 kgs)

PACKING DIEMENSIONS(L×W×H)

42"×38"×50"

42"×42"×50"
