MODEL

FR-12

FR-16

GLUING LENGTH RANGE(mm)

200-1500

200-2300

MAX.DEPTH OF CUT(mm)

75

75

MAX.SAWBLADE DIAMETER(mm)

355

355

SAWBLADE

Ø305mm

Ø305mm

SAW BLADE BORE(mm)

50.8

50.8

SAW ARBOR MOTOR (HP)

10

10

FEED DRIVE MOTOR(HP)

1.5

1.5

FEED SPEED (M/min)

14/18/24 S STEP OR

14/18/24 3 STEP OR

11-32 m/min (Optional)

11-32 m/min (Optional)

HEIGHT OF SAW ARBOR

ADJUSTABLE

ADJUSTABLE

LINK CHAIN LUBRICATION SYSTEM

STANDARD

STANDARD

(MECHANICAL TYPE)

NO. OF PRESSURE ROLLER

6

6

DISTANCE FROM SAWBLADE TO MACHINE FRAME(mm)

460

460

TABLE DIMENSIONS (L*W*H) (mm)

1400*850*800

1750*900*850

TABLE WIDTH AT LEFT OF SAWBLADE (mm)

405

455

TABLE WIDTH AT RIGHT OF SAWBLADE (mm)

445

445

PACKING DIMENSIONS(L*W*H) (mm)

1690*1560*1520

2060*1640*1580
